Needle Valves Manufacturers in india
Get An Instant Quote Now!
Fitok Valves manufacturer, supplier & exporter of Needle Valves, for the Oil, Gas, Nuclear, Petro-Chemical and Process Industries.
Fitok Valves is Manufacturer, Suppliers and Exporters of Needle Valves.
- Bar stock Body & Union Bonnet or Screwed Bonnet construction. Straight or Angle Pattern with Panel Mounting optional.
- Variety of End connections include NU Male or Female BSP,BSPT, NPT and JIS tapered, single or twin ferrule tube fittings, pipe ends.
- Maximum Working Pressure : 6000 P5I(400 ban at 200 o C. 10000 P51(700 bar) at 120 o C. Available in SS. MS & BRASS.
- 100% Factory tested.
| NEEDALE VALVE SCREW END | |
|---|---|
| SIZES | 1/8" TO 2" (3 mm to 50 mm) Max Pressure:700 BAR-10000 PSI |
| MATERIAL OF CONSTRUCTIONS- BODY & BONNET | AISI 304 ,AISI-316(CF 8 M), AISI 316 L (A 351 CF3,CF3M ), GUN METAL, ALUMINIMUM BRONZE, HAST ALLOYS, CARBON STEEL,FORGED CARBON STEEL-A 105. |
| MANUFACTURING & TESTING STANDARD | AS PER BS 5750, ISO 9002, CAN Z3 299.3 |
| END CONNECTION | Screw end BSP-F , NPT –F , BSPP-, BSPT-F SOCKETWELD END , FERRUL END , BUTT WELD END AND MALE FEMALE CONNECTIONVALVES ALSO AVAILABLE |
| SOCKET WELD END | ANSI B-16.11, ANSI B 2.1 |
| GLAND NUT | AISI 304/AISI 316 |
| BODY GASKET | PTFE/ASBESTOS/GFT ETC. |
| HAND WHEEL | BACKLITE/ ROD ROUND BAR HANDLE , METAL POWDERCOATED WHEEL OF MILD STEEL |
| HAND WHEEL NUT | S.S./M.S. |
| SPINDLE | AISI 304/AISI 316 |
